Lanry Instruments (Shanghai) Co., Ltd.
Specialize In Ultrasonic Flowmeter More Than 20 Years!
Place of Origin: | Shanghai, China (Mainland) |
Brand Name: | Lanry |
Certification: | CE |
Model Number: | TF1100-EC |
Minimum Order Quantity: | 1 Unit |
---|---|
Price: | US $108.00 - 2500/ Unit |
Packaging Details: | Carton package |
Payment Terms: | T/T, L/C |
Supply Ability: | 50pcs/day |
Product Name: | Clamp On Ultrasonic Flow Meter TF1100-EC | Output: | Datalogger/4-20mA /OCT /RS485/RS232/GPRS |
---|---|---|---|
Accuracy: | Reading+/- 1% | High Temp: | -35-200 °C |
Transducer Type: | Non-invasive | Power Supply: | 85~265VAC |
Highlight: | clamp on type ultrasonic flow meter,ultrasonic fuel flow meter |
6. Wide bi-directional flow range of 0.01 m/s to 12 m/s..
General:
1. Service and maintenance
2. Replacement of defective devices
3. Support of commissioning process and installation
4. Performance and efficiency measurement
- Evaluation and assessments
- Capacity measurement of pumps
- Monitoring of regulating valves
5. Energy efficiency audits
Water and waste water industry - hot water, cooling water, potable water, sea water etc.)
Petrochemical industry
Chemical industry -chlorine, alcohol, acids, .thermal oils.etc
Refrigeration and air conditioning systems
Food , beverage and pharmaceutical industry
Power supply- nuclear power plants, thermal & hydropower plants), heat energy boiler feed water.etc
Metallurgy and mining applications
Mechanical engineering and plant engineering-pipeline leak detection, inspection, tracking and collection.
Specifications :Transmitter
Measurement principle | Ultrasonic transit-time difference correlation principle |
Flow velocity range | 0.01 to 12 m/s, bi-directional |
Resolution | 0.25mm/s |
Repeatability | 0.2% of reading |
Accuracy | ±1.0% of reading at rates >0.3 m/s);±0.003 m/s of reading at rates<0.3 m/s |
Resonse time | 0.5s |
Sensitivity | 0.003m/s |
Damping of displayed value | 0-99s(selectable by user) |
Liquid Types Supported | both clean and somewhat dirty liquids with turbidity <10000 ppm |
Power Supply | AC: 85-265V DC: 24V/500mA |
Enclosure type | Wall-mounted |
Degree of protection | IP66 according to EN60529 |
Operating temperature | -20℃ to +60℃ |
Housing material | Fiberglass |
Display | 4 line×16 English letters LCD graphic display, backlit |
Units | User Configured (English and Metric) |
Rate | Rate and Velocity Display |
Totalized | gallons, ft³, barrels, lbs, liters, m³,kg |
Thermal energy | unit GJ,KWh can be optional |
Communication | 4~20mA(accuracy 0.1%),Frequency(1-9999Hz), Relay, RS232, RS485 (Modbus),Logged data |
Security | Keypad lockout, system lockout |
Size | 244*196*144mm |
Weight | 2.4kg |
Specifications :Transducer
Degree of protection | IP65. IP67 or IP68 according to EN60529 |
Suited Liquid Temperature | Std. Temp.: -35℃~85℃ for short periods up to 120℃ |
High Temp.: -35℃~200℃ for short periods up to 250℃ | |
Pipe diameter range | 20-50mm for type S, 40-1000mm for type M, 1000-6000mm for type L |
Transducer Size | Type S 52(h)*28(w)*26(d)mm |
Type M 60(h)*34(w)*32(d)mm | |
Type L 80(h)*40(w)*42(d)mm | |
Material of transducer | Aluminium for standard temp. sensor,and peek for high temp. sensor |
Cable Length | Std: 10m |
S 48(h)*28(w)*28(d)mm
M 60(h)*34(w)*32(d)mm
L 80(h)*40(w)*42(d)mm
With years of export experience along with excellent quality, advanced services and competitive prices, Lanry has won numerous customers' trust and support.With years of export experience along with excellent quality, advanced services and competitive prices, Lanry has won numerous customers' trust and support.
Delivery
Standard meter: 3-7 days
Special meter: pls contact us
Express, by air, by sea can be optional.
